1 | Customer | volkswagen | 12 | Mold size(mm) | 900 X1500 X 932 |
2 | Project Name | P16 | 13 | Cavity side material | 1.2344 |
3 | Part name | INLET_TANK | 14 | Core side material | 1.2344 |
4 | Part No. | 214122456A | 15 | Surface Finish - Cav | 800# |
5 | Tooling No. | CO18049 | 16 | Surface Finish - Cor | 400# |
6 | No. of cavity ( ies ) | 1 | 17 | ToolingType | 2 plate |
7 | Product Resin | PA6+GF30 | 18 | Gate Type | Needle valve directly to the product |
8 | Shrinkage | 0.50% | 19 | Hot runner system (No. of drop) | Synventive |
9 | Part Size (mm) | 66.06 X 908.50 X 186.25 | 20 | Machine tonnage | 1000T |
10 | Part Weight (g) | 1.46KG | 21 | Designed | QU |
11 | Part color | Black | 22 | Date | 2018.09.2 |
